2

Rotary diameter ≤

1100mm

3

Workpiece height ≤

950mm

4

Workpiece weight ≤

3t

5

Workbench diameter

800mm

6

Workbench speed range

7-300 rpm

7

Stage of workbench speed

High speed, 2 gears, infinitely adjustable, low gears 7-45 rpm, high gears 45-300 rpm

8

Number of feed stages for tool holder

stepless

9

Feed rate range of tool holder

0.1-2000mm/min

10

Tool holder stroke ≤ (mm)

Vertical 650

11

Rapid movement speed of tool holder

 2500mm/min

12

Blade cross-section ≤ (mm)

30×30

13

Cross beam lifting motor power

2.2KW

14

Main motor power

15KW

15

Machine weight (approximately)

6.5t

16

overall dimension

3200 long × Width 3500 × 2800 high
